An opinionated overview of a modern production Kubernetes system

This guide is a work in progress, and I intend to flesh it out with more specific details and examples.

Introduction

I've been working on a fairly modern, cloud-native software system recently that has involved a few new technologies. As a team with minimal experience building large production-ready systems from the ground up (rather, we work on a lot of giant legacy systems), there was a fairly steep learning curve. I wanted to outline some of the major components of the process so that it may serve as a guide for others going through the same thing, and to crystalise my thinking too.

This guide will walk you through the process of setting up a Kubernetes-based project, from local development to production deployment. We'll cover containerization, local Kubernetes clusters, infrastructure as code, continuous integration, and GitOps practices.

Remember that this is a high-level, opinionated overview, and the specifics will vary depending on your project requirements and preferred technologies. The goal is to provide a roadmap for building a large, modern, scalable, and reliable production system that can be worked on by a team of developers.

Standard Technologies

Here's a list of default technologies we're going to be using

  • Go for the programming language
  • K3S for local Kubernetes clusters or Minikube if you prefer
  • Docker for containerization
  • Flux for GitOps
  • Skaffold to facilitate CI/CD for local Kubernetes development
  • Kustomize for declarative management of Kubernetes resources
  • Terraform to provision cloud resources
  • AWS or GCP for cloud services

You might also use:

  • Localstack to emulate interaction with cloud resources in development

Project Structure

A typical project structure might look like this:

newproject
├── backend     # Go code, OpenAPI spec, and local cluster config
├── manifests   # Kubernetes config in YAML with overlays for prod and staging
├── terraform   # Config for provisioning cloud resources for staging and prod
└── web         # Frontend code

Deployment Process Overview

Here's an example of how a deployment process might look for a single branch project using Kubernetes:

  1. Developer checks out a new feature branch and makes code changes
  2. Developer runs skaffold dev to test changes on local K3S Kubernetes cluster
  3. Developer commits changes and pushes to remote
    • CI runs lint and test stages
  4. Developer merges feature branch to main
  5. A new tag is created for the backend repo
    • CI builds and pushes new images to container registry
    • CI updates image versions in the manifests repo's staging overlay
  6. GitOps tool (e.g., Flux) detects changes in manifests and updates the staging cluster
  7. Developer triggers production deployment
    • Changes are applied to production cluster

Setting Up Your Development Environment

We need our developers to be able to run the same code on their local machines that will eventually be run in production. This means we need to replicate the production environment as faithfully as possible. We also want the local environment to update in real time as a developer makes code changes. We can achieve this using a local Kubernetes cluster like K3S and a tool like Skaffold.

Local Kubernetes Cluster

To set up a local Kubernetes cluster for development:

  1. Install K3S on your development machine
  2. Set up your cluster configuration
  3. Run the cluster setup script

Tip: Use tools like Lens for better cluster visualization.

Running Kubernetes Resources Locally

To get a container running on your local cluster:

  1. Create a Dockerfile for your application
  2. Install Skaffold
  3. Configure skaffold.yaml to define which containers to spin up
  4. Run skaffold dev or skaffold run --tail

Managing Kubernetes Manifests

Use Kustomize to manage your Kubernetes manifests across different environments:

  1. Create a bases directory for shared configurations
  2. Create overlays directories for environment-specific configurations
  3. Use kustomization.yaml files to compose your resources

Example structure:

manifests
├── bases
│   └── daemons
│       └── api
│           ├── deployment.yaml
│           ├── kustomization.yaml
│           └── service.yaml
└── overlays
    ├── prod
    │   ├── config
    │   ├── daemons
    │   └── kustomization.yaml
    └── staging
        ├── config
        ├── daemons
        └── kustomization.yaml

Infrastructure as Code with Terraform

Use Terraform to provision your cloud resources:

  1. Set up a Terraform repository
  2. Define your infrastructure using Terraform configurations
  3. Use modules to organize and reuse your infrastructure code
  4. Provision separate environments for staging and production

Continuous Integration and Deployment

Set up your CI/CD pipeline to automate building, testing, and deploying your application:

  1. Configure your CI tool to build images when pushing to the main branch
  2. Set up jobs to deploy images to your container registry
  3. Implement a versioning strategy (e.g., using Git tags)
  4. Configure your CI to update manifests with new image versions.
    • These will then be applied to your cluster by your GitOps tool (Flux in our case).

GitOps with Flux

Use Flux to keep your cluster in sync with your manifests:

  1. Install Flux on your Kubernetes cluster
  2. Configure Flux to watch your manifests repository
  3. Set up webhooks to alert Flux of changes to the manifests

Flux will automatically apply changes pushed to your manifests repository to your Kubernetes cluster, ensuring your desired state is always reflected in your running infrastructure.

Conclusion

The above guide should give you a good starting point for building a modern Kubernetes production system. The details are quite sparse, but I hope that the outline can give you a path towards a robust and scalable system that can handle the demands of modern production system. Good luck!
